| Supported CPU | Supports 12th/13th Gen Intel Core Processors, Pentium Gold And Celeron Processors LGA1700 |
| Chipset | INTEL B760 |
| Form Factor | 2x PCI-E X16 Slot Supports X16/X4 1x PCI-E X1 Slot PCI_E1 PCIe 5.0 Supports Up To X16 (From CPU) PCI_E2 PCIe 3.0 Supports Up To X4 (From Chipset) PCI_E3 PCIe 4.0 Supports Up To X1 (From Chipset) |
| Audio | Realtek ALC897 Codec 7.1-Channel USB High-Performance Audio Supports S/PDIF Output |
| Maximum Memory | 128GB |
| Slots | 4 |
| Supported Memory | 4x DDR5, Maximum Memory Capacity 128GB Memory Support 7000+(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. Overclocking Frequency: • 1DPC 1R Max Speed Up To 7000+ MHz • 1DPC 2R Max Speed Up To 6600+ MHz • 2DPC 1R Max Speed Up To 6400+ MHz • 2DPC 2R Max Speed Up To 5600+ MHz Supports Dual-Channel Mode Supports Non-ECC, Un-Buffered Memory Supports Intel® Extreme Memory Profile |
| Graphics | 1x HDMI™ 1x DisplayPort Support HDMITM 2.1 With HDR, Maximum Resolution Of 4K 60Hz* Support DP 1.4, Maximum Resolution Of 8K 60Hz* |
| Internal I/O Ports | 1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
5x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x TBT Connector (JTBT, Supports RTD3)
1x Tuning Controller Connector(JDASH) 2x Addressable V2 RGB LED Connector (JARGB_V2) 2x RGB LED Connector(JRGB) 4x USB 2.0 2x USB 3.2 Gen1 Type A 1x USB 3.2 Gen2 Type C |
| Supported Storage | 3x M.2 Slot M.2_1 (From CPU) Supports Up To PCIe 4.0 X4 , Supports 22110/2280/2260/2242 Devices M.2_2 (From Chipset) Supports Up To PCIe 4.0 X4 , Supports 2280/2260/2242 Devices M.2_3 (From Chipset) Supports Up To PCIe 4.0 X4 / SATA Mode, Supports 2280/2260/2242 Devices 4x SATA 6G Port |
| Manufacturing Warranty | 3 Years |
The MSI MAG B760 TOMAHAWK WIFI DDR5 13th Gen & 12th Gen ATX Motherboard is a high-performance motherboard designed to support the latest generation of Intel processors. With its robust features and cutting-edge technology, it delivers exceptional performance and reliability for gaming and demanding computing tasks.The motherboard supports both 12th and 13th Gen Intel Core processors, Pentium Gold, and Celeron processors, providing a wide range of options to suit various user requirements. It features the LGA1700 socket and is built on the INTEL B760 chipset, ensuring compatibility and optimal performance.With four DDR5 memory slots, this motherboard supports a maximum memory capacity of 128GB. It offers memory support for impressive frequencies, including overclocking capabilities up to 7000+ MHz (OC). It supports dual-channel mode, non-ECC, un-buffered memory, and Intel Extreme Memory Profile for enhanced performance and stability.The graphics capabilities of the MSI MAG B760 TOMAHAWK motherboard are impressive. It features an HDMI port and a DisplayPort, supporting HDMI 2.1 with HDR and a maximum resolution of 4K 60Hz, as well as DP 1.4 with a maximum resolution of 8K 60Hz. This ensures stunning visuals and immersive experiences for gaming and multimedia applications.The motherboard provides excellent storage options with three M.2 slots and four SATA 6G ports. The M.2 slots support PCIe 4.0 x4 and SATA devices, allowing for high-speed SSD storage solutions. Additionally, the motherboard features a Realtek 2.5Gbps LAN for fast and stable network connectivity.For audio, the MSI MAG B760 TOMAHAWK motherboard incorporates the Realtek ALC897 Codec, providing 7.1-channel USB high-performance audio. It also supports S/PDIF output, ensuring immersive and high-quality sound for gaming and entertainment.In terms of connectivity, the motherboard offers a range of USB ports, including USB 2.0, USB 3.2 Gen1 Type A, USB 3.2 Gen2 Type A, and USB 3.2 Gen2 Type C, providing convenient options for connecting various devices. The motherboard also includes internal I/O ports for easy installation and expansion, such as power connectors, fan headers, RGB LED connectors, and USB headers.The MSI MAG B760 TOMAHAWK WIFI motherboard features built-in Intel Wi-Fi 6E, ensuring fast and reliable wireless connectivity. The pre-installed wireless module supports MU-MIMO TX/RX and offers support for multiple Wi-Fi standards, including 802.11 a/b/g/n/ac/ax.With its ATX form factor, the motherboard offers a standard size that is compatible with a wide range of cases. It features multiple PCI-E slots for expansion, including two PCI-E x16 slots, one PCI-E x1 slot, and additional connectivity options such as HDMI.
MSI MAG B760 TOMAHAWK WIFI motherboard is designed for gamers and enthusiasts, with a 12+1+1 dual rail power system and 8+8 pin power connectors to support the Core Boost technology, which boosts the performance of your multi-core Intel processor. Overclock your CPU with ease thanks to MSI Game Boost technology, which allows for 1-second rapid overclocking. The Digital Power Design, Overvoltage Protection, Load-Line Calibration, Double Power Connectors, and Supplemental PCIe Power Connectors on the motherboard all work together to provide proper electrical management through your system to stabilize your system, especially under high loads.
The MSI MAG B760 TOMAHAWK WIFI Motherboard features Extended Heatsink Design and M.2 Shield Frozr and is designed for high-performance systems and continuous operation. This motherboard’s increased cooling capabilities will keep your components working at optimal temperatures. M.2 Shield Frozr, Fully Fan Control, Frozr AI Cooling, and System Cooling all work together to keep your components cool even while under high loads when gaming or generating content.
The MSI MAG B760 TOMAHAWK WIFI 13th Gen Motherboard features a PCB optimized for higher bandwidth and faster transfer speeds, as well as reliable circuit transmission with 2oz thickened copper that allows the motherboard to easily withstand overclocking while improving heat dissipation and system reliability. The MSI PCI Express Steel Armor slot is soldered to the motherboard to handle the weight of large graphics cards and avoid GPU droop, which can damage PCIe slots. The grounding layer around the mounting holes is doubled for double ESD protection, preventing static discharge spikes from damaging the motherboard.
The MSI MAG B760 TOMAHAWK WIFI Motherboard includes the Realtek ALC897 Codec as well as 7.1-Channel USB High-Performance Audio. Immerse yourself in your favorite media with Audio Boost technology, which includes high-quality audio capacitors, 3.5mm audio connectors with S/SPDIF, and a dedicated high-definition audio processor. The printed circuit board isolates audio layers for clear left and right channels, as well as isolating audio circuits to reduce crossover talk and electrical interference. To protect your ears, de-pop protection eliminates the popping sound caused by plugging or unplugging audio devices.
Connect to your network wirelessly using Wi-Fi 6 (802.11ax) technology, which provides faster wireless rates and efficiency, making it ideal for uploading and downloading large files. This motherboard also has a 2.5 Gigabit Ethernet connection for wired networking. MSI’s LAN Manager software prioritizes your connection, eliminating lag and maintaining a pleasant online experience.
The latest price of MSI MAG B760 TOMAHAWK WIFI DDR5 INTEL 13TH & 12TH GEN ATX MOTHERBOARD in Bangladesh is 26,000৳ You can buy the MSI MAG B760 TOMAHAWK WIFI DDR5 INTEL 13TH & 12TH GEN ATX MOTHERBOARD at best price from our Website or visit any of our showrooms.
